DXDF Automatic Powder Packaging Machine

The DXDF Automatic Powder Packaging Machine is equipped with antipollution and dustproof device

Product Recommendation

  • Product Introduction
  • Product Parameter
  • Product Picture
  • Product Comment

Introduction of DXDF Automatic Powder Packaging Machine

ⅠDXDF Automatic Powder Packaging Machine Applications:

Specially designed and manufactured DXDF Automatic Powder Packaging Machine for powdery and super fine powdery products Driven by servomotor, the auger is rotating to fill products; furthermore, the filling range can be adjusted automatically through computer The processes of bag making, measuring, filling, sealing, cutting, counting and hot pressing codes can be done automatically. Packing material include several kinds of heat-seal lamination, such as PET/plated AL/PE, PET/PE, NYLON etc.
Ⅱ DXDF Automatic Powder Packaging Machine Features:
1. All stainless steel cover meets to GMP standard.
2. Equipped with antipollution and dustproof device.
3. Automatic adjustment of pouch size and filling range.
4. Photocell controller is easy to manipulate.
5. Automatic self support lubricating system, the machine can work 24 hours
6. The operation facility is controlled by American intel computer, all function is displayed with digital screen.
7. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by ± 2%.
8. Along with assembling automatic no packing alarm system, help user to economize cost.
9. Equipped with easy open system.
10. Equipped long filling screw make the sealing area clean and strong and compact shut-off door is used to prevent from product clamping at sealing jaw.
Ⅲ DXDF Automatic Powder Packaging Machine Option
1.Ink printer
2.Conveyor
3. Hot printing code

Parameter of DXDF Automatic Powder Packaging Machine

TYPE

DXDF-40II

DXDF-150II

Bag size

L55-110 /W30-80mm

L70-150 /W70-115mm

Capacity

50-110 bags/min

28-60 bags/min

Filling range

5-40 ml

30-150 ml

Power

220V,50HZ,1.5KW

220V,50HZ,1.9KW

Weight

350  KGS

450  KGS

Dimension(L*W*H)

600X 790X1780 mm

700X 800X1900 mm

Pictures of DXDF Automatic Powder Packaging Machine
