Parameters And Operation Steps Of Chamber Vacuum Machine

Chamber Vacuum Machine is featured by automatic processing of vacuuming, sealing, printing, cooling in one operation. Next, let me briefly introduce the parameters and operation steps of chamber vacuum machine for you.

First, the parameters of chamber vacuum machine.

Model parameters: 400-A

Power supply voltage: 220V 50Hz

Power parameter: 1.5KW

Vacuum chamber size: 420X440X115mm

Sealing length: 400X10mm

Packing speed: 1-4pec/min

Weight: 105kgs

Dimensions: 660X600X1010mm

Second, the operation steps of chamber vacuum machine.

Operation step 1: Power on the chamber vacuum machine: flip the power selection switch as required, that is, the power indicator is on. The power selector switch points to vacuum for vacuum sealing, and points to vacuum inflation for vacuum inflation sealing.

Operation step 2: Put the plastic bag containing the articles into the vacuum chamber. The mouth of the bag should be neatly placed on the heat seal (for inflatable packaging, at least one nozzle should be inserted into the mouth of the bag).

Operation step 3: Press down the cover of the chamber vacuum machine, and the suction (vacuum) indicator on the panel lights up. Vacuum pump began to pump, the cover is automatically sucked, vacuum knob can be adjusted according to the packaging requirements of the vacuum degree, adjustment, the scale from low to high, the range should be small.

Operation step 4: when pumping reaches the set time (that is, the required vacuum degree), that is, the end of pumping, pumping indicator light out, inflation indicator light, indicating the beginning of inflation. The inflation knob can adjust the inflation time (i.e. the amount of air), the method is the same as above. If you do not need to inflate. Turn the power switch to the vacuum position, the program will automatically enter the vacuum packaging, and the inflation indicator will be off.

Operation step 5: when the air pumping or inflation is completed, the chamber vacuum machine indicator light goes out and the heat sealing indicator lights up, that is, the sealing procedure is entered. The panel is equipped with the heat sealing time and temperature adjustment knob to adapt to different thickness materials. When adjusting the time and temperature, the rotation amplitude should be small to prevent the heat sealing temperature from increasing suddenly and burning the heat sealing accessories.

Operation step 6: When the set heat sealing time is reached, the heat sealing indicator light will be off, which proves the end of heat sealing. That is, the vacuum chamber will enter the atmosphere through the solenoid valve until the cover of the chamber vacuum machine is lifted automatically. The vacuum charging packaging process is all finished and the next packaging cycle is ready.
