The
continuous band sealer is suitable for sealing various sizes of packages. It adopts electronic constant temperature control and stepless speed regulation transmission mechanism, which can automatically and continuously seal plastic films of various materials; it can also be equipped with an indentation printing wheel and a counting device as required; High speed, high efficiency, low loss, low pollution and automation are the standard features of
continuous band sealer.
Parameters Of Universal Continuous Band Sealer
Take the general-purpose
continuous band sealer as an example
1. Power supply voltage: (V/HZ) AC 220/50 110/60
2. Motor power (W) 50W
3. Electric heating power (W) 300×2
4. Sealing line speed (M/MIN) 0-12 (0-16)
5. Sealing width (MM) 8 10
6. Temperature control range (℃) 0-300
7. Printing type Drum indentation printing (optional)
8. The distance between the sealing center and the conveying table (MM) is 10-40
9. Conveyor table size (L×W) (MM) 840×180
10. The maximum carrying weight of a single piece of the conveying table (KG) ≤ 1
11. The total carrying weight of the conveying table ≤3
12. Dimensions (L×W×H) (MM) 840×550×800
13. Net weight (KG) 40
