Do You Know How To Operate The Chamber Vacuum Machine?

1. Chamber vacuum machine installation film: when the film frame is on the work surface, after opening the upper frame

2. The chamber vacuum machine pulls the film slightly beyond the right edge of the frame, and presses the upper frame to clamp the film.

3. Chamber vacuum machine lift: Check whether the “frame position selection” switch is in the “continuous” position, press the “rise” switch k

4.The chamber vacuum machine can then automatically stop by the fixed point which is controlled by the proximity switch. The film roll must be loosened before lifting the frame, so as to prevent the film frame from rising due to the adhesion between the films.

5. Chamber vacuum machine Put the tray with the packaged items in the vacuum chamber of the working vacuum packaging machine. Tools should be used instead of pushing directly by hand, in case of failure of the electrical appliance and causing personal injury.

6. Press the "automatic packaging" switch in the chamber vacuum machine, the three processes of film heating, heat preservation and air extraction are completed automatically from the adjusted time.

7.Vacuum vacuum machine When the membrane frame is automatically lowered to the low point controlled by the limit switch, the vacuum pump will evacuate the vacuum chamber. In this case, it is found that the pointer of the vacuum meter of the vacuum packaging machine has no action, indicating that the vacuum pump motor is running in the reverse direction. Stop immediately and adjust any two phases in the input phase line before restarting the program.

8. The chamber vacuum machine opens the upper frame, pulls the packaged items to the right, places them on the auxiliary workbench, depresses the upper frame, cuts the packaged items, and completes the packaging.

9. The chamber vacuum machine starts to operate from the items in the operation program, and the cycle starts.
