Chamber Vacuum Machine Repair Knowledge

In order to make the chamber vacuum machine work better for us and extend the service life of the chamber vacuum machine, the user must regularly carry out effective maintenance and maintenance when purchasing the chamber vacuum machine. So what are the maintenance skills of the chamber vacuum machine? Here is a brief introduction for you:

1. The chamber vacuum machine should be in the environment of temperature -10 °C - 60 °C, relative humidity is not more than 85%; no corrosive gas in the surrounding air, no powder, no explosive dangerous goods.

2. The vacuum pump oil level should be checked regularly, and the oil level should be added regularly to keep the oil level in the oil window 1/2 to 3/4 position; the vacuum pump adopts imported No. 30 automobile engine oil or vacuum No. 0 pump special oil.

3. When it is observed that the oil in the pump turns black or white, there is water droplets in the oil, or the viscosity increases, it proves that the oil has been contaminated, and the oil should be replaced immediately. Under normal circumstances, replace the oil every 1-2 months of continuous operation.

4. The model with water removal device should be drained regularly from the drain pipe at the rear of the equipment according to the moisture content of the packaged material. After draining, put the pipe plug, the water will be automatically decomposed and no discharge is required.

In addition, in addition to the above preparations, the chamber vacuum machine needs to do the following two points in order to make the chamber vacuum machine work better.

1. According to the speed of the automatic operation of the working chamber on the chamber vacuum machine and the working speed of the operator, the time adjustment time relay on the vacuum chamber of the chamber is lengthened or shortened.

2. There is an emergency stop switch on the chamber vacuum machine. If there is a special case, press this switch, the upper cover will automatically open at the top, wait for the situation to be eliminated, open the emergency stop switch, push the upper cover to the working side, and the equipment will enter the normal work. status.
